Researchers Improve Next Generation Aircraft Engines

Editor

27 Nov 2019 — 3 min read

Eric Wood (left) from the University of Illinois at Urbana-Champaign and Eric Mayhew (right) from the CCDC Army Research Laboratory prepare for high-speed X-ray phase contrast imaging experiments of reacting fuel spray breakup

The Army’s Future Vertical Lift program is one of the modernization priorities for Army leadership. With the use of advanced X-ray diagnostics, scientists have a better understanding of gas turbine combustor inlet conditions, which is critical for the design and development of engines for the next generation of Army aircraft.

The FVL concept is to create a new rotorcraft that uses new technology, materials and designs that are quicker, have further range, better payload, are more reliable, easier to maintain and operate, have lower operating costs and can reduce logistical footprints.

That is the focus of a team of Army and university researchers. Through an essential research program known as Versatile Tactical Power and Propulsion, they developed a single sector gas turbine combustor experimental capability to study the variation in the breakup and atomization of fuel sprays while combusting using high-speed X-ray phase contrast imaging.

U.S. Army Combat Capabilities Development Command‘s Army Research Laboratory researchers along with University of Illinois at Urbana-Champaign professor Tonghun Lee and graduate students from his research group designed and built out the combustor and associated experimental apparatus. The team conducted their experiments at Argonne National Laboratory’s Advanced Photon Source, assisted by Dr. Alan Kastengren, beamline scientist at ANL.

computation fluid dynamics

To develop these kinds of models, scientists said they employ carefully designed experiments that simulation experts can use to inform and validate their codes.

“Traditionally, sprays have been studied experimentally using a range of optical and laser diagnostics, which have been used to study droplet distributions, velocities and dynamics,” Mayhew said. “However, researchers have had difficulty using these traditional diagnostics to examine the spray as it is just leaving the tip of the nozzle or injector due to the optical density of the spray as is leaving the tip of the nozzle or injector.”

Researchers said this spray breakup and atomization process is especially challenging with the addition of ongoing combustion as the flame naturally emits light at wavelengths used for traditional optical and laser diagnostics on top of the numerous additional safety issues.

the Advanced Photon Source

To study the effects of different kinds of fuels on atomization and ignition processes, ARL, UIUC and industry scientists designed the ARL research combustor-midsize 1, or ARC-M1 and ARL research combustor-large 1, or ARC-L1. Both combustors simulate a single combustor cup of a gas turbine aircraft engine; in a real gas turbine engine, several identical combustors would be located in a ring around the aircraft engine’s central axis, operating in tandem.

High-speed X-ray phase contrast imaging experiments were performed on combusting fuel spray breakup in the Army Research Combustor-M1. These unique measurements provide understanding of the fundamental processes of spray breakup that will help in the development of multi-fuel capable engines

“The ARC-M1 and L1 systems are interrogated using the most advanced diagnostics possible — the measurements at the Argonne APS are part of this effort,” Lee said. “As a consequence, we anticipate gaining critical insight into the physicochemical dynamics of advanced gas turbine propulsion systems for future Army vehicles.”

Researchers are encouraged by the results.

“While the first experiments explored the simplified system of the interaction of a water spray with the turbulent, swirl of the ARC-M1, the second phase of experiments in April 2018 were the first spray combustion experiments ever conducted at APS,” Mayhew said. “Additional improvements and modifications were made to the experimental setup to enable the most recent experiments conducted in August 2019, with combustor pressures up to three times atmospheric pressure, which closely simulate inlet conditions in current Army vehicles.”

The researchers are advancing the experimental setup and designs to get to relevant conditions to the Army systems, said the lab’s Dr. Mike Kweon, program manager. He said they are adding a capability to simulate altitude conditions at ANL’s APS.

engine development

“The new discovery and understanding of atomization process in combustion of gas turbine aircraft engines can lead to innovation in spray and evaporation models that can be used in commercial CFD tools.”

This research supports the U.S. Army’s Future Vertical Lift modernization priority, Kweon said.
